Enware Front of Wall Component Auto Sense – (ENMA)

Touch free sensor tap with a beneath outlet infra-red sensor activation is designed for general hand hygiene within health care and food preparation facilities. Designed for effective reduction of Legionella risk. Features flush cycles and smooth bore spout design. Adjustable temperature range for user comfort. AHFG Type A and B healthcare basin compatibility. Smart, durable easy-clean chrome surfaces and sealed face plate minimises egress of moisture into wall cavity and contaminated air flow from wall cavity into sterile areas.

Key features

  • Smooth bore tubular spout designed to minimise bacteria growth
  • 12-hour flush cycle eliminates stagnation in water supply lines greatly reducing the risk of bacteria growth
  • Potentially contaminated air is elminated from the water stream with laminar flow controlled spout
  • Low voltage 6V battery operated or 12V mains supply
  • Back and front of wall components are separate order codes and can be supplied separately to meet construction needs
  • Face plate removes to access integral isolation/check valves, strainers and inspection ports for TMV servicing requirements

Important Downloads

Downloads

Out of stock

SKU: ENMA Categories: , , ,

Additional information

Inlet Connection

15mm (1/2") BSP

Minimum-Maximum Working Pressure (AS/NZS 3500)

50-500kPa

Maximum Static Pressure

800kPa

Maximum Temperature

70 C

Time Flow Specifications ENM5071

Adjustable flow time to 3, 6, 9 or 12 seconds. (Default 6 seconds)

Wave-On Wave-Off Specifications ENM5072

45 seconds maximum run time if not waved off by user.

Power Supply

24V AC

Sensor Range

Approx. 170mm
